Ubiquiti UniFi U7 Long-Range Access Point |

Ubiquiti Unifi Access Point U7 Long Range

Key features
WiFi 7 technology: Supports the latest Wi-Fi 7 (802.11be) standard for next-generation wireless performance.
Dual-band: Operates on the 2.4 GHz and 5 GHz bands, offering a combined throughput of up to 4988 Mbps.
Long-range coverage: Features an internal high-gain antenna array engineered for extended signal strength over large areas, estimated at about 1,750 square feet (160 square meters).
High client capacity: Can handle over 300 concurrent client connections.
2.5 GbE uplink: Equipped with a 2.5 Gigabit Ethernet port for high-speed wired backhaul, supporting Power over Ethernet (PoE+).
Advanced wireless technology: Utilizes Multi-Link Operation (MLO), MU-MIMO, and OFDMA technologies to improve signal clarity and efficiency, especially in dense network environments.
Robust design: Has an IP54-rated enclosure, offering resistance to dust and light water splashes for semi-outdoor installations.

₦320,000.00

Ubiquiti UniFi U7 Long-Range Access Point (U7-LR)

The Ubiquiti UniFi U7 Long-Range Access Point is engineered for extended coverage and high client density. As part of the UniFi ecosystem, it is managed through the UniFi Network Application and works well alongside a UniFi Dream Router 7 (UDR7) or other UniFi gateway for a complete managed network.

Key Features

  • WiFi 7 (802.11be) support for next-generation wireless performance
  • Dual-band operation (2.4GHz and 5GHz) with combined throughput up to 4,988 Mbps
  • Internal high-gain antenna array for extended coverage, up to 1,750 sq ft (160 sq m)
  • Supports over 300 concurrent client connections
  • 2.5 GbE uplink port with PoE+ support for high-speed wired backhaul
  • Multi-Link Operation (MLO), MU-MIMO, and OFDMA for improved efficiency in dense environments
  • IP54-rated enclosure – resistant to dust and light water splashes for semi-outdoor installs
  • Ceiling or wall mounting, managed centrally through the UniFi Network app

Who Is the Ubiquiti UniFi U7 Long-Range Access Point For

The U7-LR suits offices, schools, and warehouses needing reliable WiFi 7 coverage across large or open areas, IT administrators already using UniFi gear who want centralized management alongside their existing gateway and switches, and businesses with high device density that need strong concurrent client handling.

Full Specifications

Wireless Performance

Spec Detail
WiFi Standard WiFi 7 (802.11be)
Bands 2.4GHz and 5GHz (dual-band)
Max Data Rate 688 Mbps (2.4GHz), 4.3 Gbps (5GHz), 4,988 Mbps combined
Spatial Streams 5
Coverage Area Up to 160 sq m (1,750 sq ft)
Max Clients 300+

Connectivity & Design

Spec Detail
Uplink 2.5 GbE, PoE+ powered
Mounting Ceiling or wall
Enclosure Rating IP54 (dust and light splash resistant)
Management UniFi Network Application

Why Buy from Foretec Online

  • Genuine, sealed products sourced for the Nigerian market
  • Transparent Naira pricing with no hidden charges
  • Fast delivery across Abuja, Lagos, Kano, Port Harcourt, and beyond
  • Responsive customer support before and after your purchase

Order the Ubiquiti U7-LR Today

This unit is new and sealed. Browse more access points and UniFi networking gear from Foretec, pair it with the UDR7, or order the U7-LR now.

SKU: U7-LR Categories: ,

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “Ubiquiti Unifi Access Point U7 Long Range”

There are no reviews yet.

FAQs

Does the U7-LR support 6GHz WiFi?
No, the U7-LR is a dual-band access point supporting 2.4GHz and 5GHz only. Ubiquiti's U7 Pro and U7 Pro Max models add 6GHz support.
How many devices can the U7-LR support?
Over 300 concurrent client connections.
Can the U7-LR be installed outdoors?
It has an IP54 rating, making it suitable for semi-outdoor installations with light water splash exposure, but it is not designed as a fully outdoor access point.
Do I need other UniFi equipment to use this access point?
The U7-LR is managed through the UniFi Network Application, so it works best alongside a UniFi gateway or controller such as the UDR7.
Is this unit new?
Yes, this unit is sold new and sealed by Foretec.

Dimensions
Ø175.7 x 43 mm (Ø6.9 x 1.7″)
WiFi Standard
WiFi 7
Spatial Streams
5
Coverage Area
160 m² (1,750 ft²)
Max. Client Count
300+
Uplink
2.5 GbE
Mounting
Ceiling, Wall (Plastic Mounting Plate included)
Power Method
PoE

MIMO

5 GHz

3 x 3 (DL/UL MU-MIMO)

2.4 GHz

2 x 2 (DL/UL MU-MIMO)
Max. Data Rate

5 GHz

4.3 Gbps (BW160)

2.4 GHz

688 Mbps (BW40)
Antenna Gain

5 GHz

6 dBi

2.4 GHz

4 dBi
Max. TX Power
5 GHz
27 dBm

2.4 GHz

26 dBm
Supported Data Rates

802.11be (WiFi 7)

7.3 Mbps to 4.3 Gbps (MCS0 – MCS13 NSS1/2/3, EHT 20/40/80/160)

802.11ax (WiFi 6)

7.3 Mbps to 3.6 Gbps (MCS0 – MCS11 NSS1/2/3, HE 20/40/80/160)

02.11ac (WiFi 5)

6.5 Mbps to 2.6 Gbps (MCS0 – MCS9 NSS1/2/3, VHT 20/40/80/160)

802.11n

6.5 Mbps to 450 Mbps (MCS0 – MCS23 , HT 20/40)

Wireless Meshing
✓
Band Steering
✓
802.11v BSS Transition Management
✓
802.11r Fast Roaming
✓
802.11k Radio Resource Management (RRM)
✓
Advanced Radio Management
✓
Passpoint (Hotspot 2.0)
✓
Captive Hotspot Portal

Custom Branding Landing Page

✓

Voucher Authentication

✓

Payment-Based Authentication

✓

External Portal Server Support

✓

Password Authentication

✓

Guest Network Isolation

✓
Private Pre-Shared Key (PPSK)
✓
WiFi Speed Limiting
✓
Client Device Isolation
✓
WiFi Schedules
✓
RADIUS over TLS (RadSec)
✓
Dynamic RADIUS-assigned VLAN
✓

Max. Power Consumption
14W
Supported Voltage Range
42.5—57V DC
Networking Interface
(1) 2.5 GbE RJ45 port
Weight
448 g (15.8 oz)
Management
Ethernet
Enclosure Material
Polycarbonate, aluminum alloy
Mount Material
Polycarbonate, galvanized steel (SGCC)
LEDs

System

White/Blue
Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160 (MHz)
NDAA Compliant
✓
Certifications
CE, FCC, IC, Anatel
Ambient Operating Temperature
-30 to 50° C (-22 to 122° F)
Ambient Operating Humidity
5 to 95% noncondensing

Application Requirements

UniFi Network

Version 9.1.120 and later

Mobile App

iOSâ„¢ version 10.20.2 and later Androidâ„¢ version 10.21.7 and later
