Ubiquiti Unifi U6 Wifi
Enterprise-grade WiFi 6 access point with 4X4 MIMO and OFDMA functionality.
The Access Point WiFi 6 Long-range (U6 LR) is a high-performance access point that brings powerful, four-stream WiFi 6 coverage to enterprise networks. The U6 LR can reach an aggregate throughput rate up to 3 Gbps with its 5 GHz (4×4 MU-MIMO and OFDMA) and 2.4 GHz (4×4 MIMO) bands. It also has a sideways, down-tilted antenna pattern to expand its coverage area. The water and dust-resistant U6 LR can be mounted either indoors or outside, blending seamlessly into virtually any environment so you’ll never have to disrupt your space’s aesthetic to enjoy excellent wireless coverage. The U6 LR simplifies the process of bringing WiFi 6 to enterprise networks that support a large number of clients. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.
Ubiquiti Unifi U6 Wifi Four-stream high-efficiency Wi-Fi 6 technology
Wi-Fi 6 APs deliver an aggregate radio rate of up to 3 Gbps with 5 GHz (4×4 MU-MIMO and OFDMA) and 2.4 GHz 4×4 MIMO radios
Powerful, wider wireless coverage
The U6-LR access point utilizes Wi-Fi 6 technology to provide strong and expansive wireless coverage to all enterprise networking environments.
Simultaneously connect to more devices
Create and support over 300 distinct client connections.
Easily set up and grow your network
The Ubiquiti Unifi U6 Wifi access point seamlessly integrates with the UniFi Network Application and simplifies network bridging.
Host, configure, and monitor all of your network devices from a central mobile interface.
Ubiquiti Unifi U6 Wifi Specifications
| Model | U6-LR |
|---|---|
| Wi-Fi Standard | Wi-Fi 6 (802.11ax), also supports 802.11a/b/g (Wi-Fi 4/Wi-Fi 5) |
| MIMO | 4×4 on both 2.4GHz and 5GHz bands |
| Throughput Rate | 2.4GHz: 600 Mbps, 5GHz: 2400 Mbps (aggregate up to 3 Gbps) |
| Antenna Gain | 2.4GHz: 4 dBi, 5GHz: 5.5 dBi |
| Max TX Power | 2.4GHz: 26 dBm, 5GHz: 26 dBm |
| Spatial Streams | 8 total |
| Coverage Area | Up to 185 m² (2,000 ft²) |
| Max Client Count | 350+ |
| Processor | Dual-core Cortex A53, 1.35 GHz |
| Memory | 512 MB |
| Networking Interface | 1x GbE RJ45 port (PoE In) |
| Management Interface | Ethernet, Bluetooth |
| Power Method | 802.3at PoE+ / Passive PoE (48V) |
| Power Supply | 48V, 0.5A PoE adapter (not included) |
| Max Power Consumption | 18.5W |
| Supported Voltage Range | 44-57V DC |
| Weatherproofing | IP54 (indoor/semi-outdoor mounting) |
| Mounting | Wall/ceiling (Pro Mount included) |
| Enclosure Material | Polycarbonate |
| Mount Material | Stainless steel (SUS304) |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| VLAN | 802.1Q |
| QoS | Per-user rate limiting |
| Operating Temperature | -30°C to 60°C (-22°F to 140°F) |
| Operating Humidity | 5-95% noncondensing |
| Dimensions | Ø220 x 48 mm (Ø8.7 x 1.9 in) |
| Weight | 800g without mount, 930g with mount |
| Certifications | CE, FCC, IC |
| Condition | New |
| Warranty | 1 Year |
