• Tplink 10-Port Gigabit Desktop Switch
Tplink 10-Port Gigabit Desktop Switch

Tplink 10-Port Gigabit Desktop Switch with 8-Port PoE+ TL-SG1210P

  • 9 10/100/1000Mbps RJ45 ports, 1 Gigabit SFP port
  • With 8 PoE+ ports, transfers data and power on one single cable
  • Works with IEEE 802.3af/at compliant PDs and expands office network
  • 802.1p/DSCP QoS enable smooth latency-sensitive traffic
  • High PoE power budget with up to 30W for each PoE port and 63W for all PoE ports
  • Easy to use, with no configuration and installation needed

₦110,000.00

Tplink 10-Port Gigabit Desktop Switch

PoE Switches for Your Ultra Convenience
10-Port Gigabit Desktop Switch with 8-Port PoE+
TL-SG1210P

Featuring
Surveillance
Work with IP Cameras
Conference Call
Work with IP Phones
Wi-Fi Coverage
Work with Omada EAPs

Easy to Use
Connect To Power
Connect To DevicesIP-phoneAcces PointIP-CameraInternetRouterTL-SG1210P
Enjoy
Power over Ethernet (POE)
Port 1-8 of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af/at compliant Powered Devices (PDs).

Intelligent Power Management
When total power consumption excels 63W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.

Power overload63WPower Management Intelligent power supply 63W
Advanced Functions for Higher Performance

For Fluent Online Experience
Administrators can designate the priority of traffic based on QoS, for example, to ensure that voice and video applications remain clear and lag-free.

Traffic Optimization for IPTV
IGMP Snooping optimizes multimedia traffic delivery, to ensure a better network experience especially for applications like IPTV.

Sturdy Metal Casing
Sturdy, compact metal casing, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

Specifications

Model TL-SG1210P
Type Unmanaged desktop switch
Interface 8x PoE+ 10/100/1000Mbps RJ45 ports, 1x 10/100/1000Mbps RJ45 uplink port, 1x Gigabit SFP slot
PoE Standard IEEE 802.3af/at compliant
PoE Power Budget 63W total, up to 30W per port
Switching Capacity 20 Gbps
QoS 802.1p/DSCP
Multicast Optimization IGMP Snooping
MAC Address Table 4K
Extend Mode Range Up to 250m data and power transmission
Special Modes Priority Mode (ports 1-2), Isolation Mode, PoE Auto Recovery
Dimensions (W x D x H) 209 x 126 x 26 mm
Max Power Consumption 7.11W (no PD connected), 78.13W (63W PD connected)
Certification CE, FCC, RoHS
Condition New
Warranty 1 Year
SKU: TL-SG1210P Categories: ,

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “Tplink 10-Port Gigabit Desktop Switch with 8-Port PoE+ TL-SG1210P”

There are no reviews yet.

FAQs

How many ports does the TL-SG1210P have?
It has 9 10/100/1000Mbps RJ45 ports (8 of which support PoE+) plus 1 Gigabit SFP slot, for 10 ports total.
What is the total PoE power budget?
It has a total PoE power budget of 63W, with up to 30W available per port.
Does this switch require configuration?
No, it is an unmanaged, plug-and-play switch that works immediately with no configuration needed.
What devices can this switch power?
It supports any IEEE 802.3af/at compliant Powered Device (PD), such as IP cameras, wireless access points, and IP phones.
What happens if PoE devices exceed the power budget?
Intelligent power management automatically prioritizes higher-priority ports and cuts power to lower-priority ports to protect the switch from overload.
Is this unit new, and what warranty does it come with?
Yes, this unit is sold new by Foretec Online and comes with a 1-year warranty.

HARDWARE FEATURES
Interface 8 PoE+ 10/100/1000Mbps RJ45 Ports
1 10/100/1000Mbps RJ45 Port
1 Gigabit SFP Slot
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-X MMF, SMF
Fan Quantity Fanless
Physical Security Lock Yes
Power Supply External Power Adapter(Output: 53.5VDC / 1.31A)
Packet Forwarding Rate 14.88 Mpps
PoE+ Ports(RJ45) Standard: 802.3at/802.3af compliant
PoE Ports: Port1- Port 8
PoE Power Budget: 63W
Mac Address Table 4K
Jumbo Frame 16 KB
Switching Capacity 20 Gbps
Dimensions ( W x D x H ) 209 × 126 × 26 mm
Max Power Consumption 7.11 W (220/50Hz. no PD connected)
78.13 W (220/50Hz. with 63W PD connected)
Max Heat Dissipation 24.25 BTU/h (no PD connected)
266.42 BTU/h (with 63W PD connected)
SOFTWARE FEATURES
Advanced Features Compatible With IEEE 802.3af/at Compliant PDs
EEE802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
Transmission Method Store-And-Forward
OTHERS
Certification CE, FCC, RoHS
Package Contents TL-SG1210P, Power Adapter, Installation Guide
Environment Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing
