Aspect Ratio                                                                                   4:3

Brightness                                                                                       3,200 ANSI lumens

Compatible Aspect Ratio                                                              4:3 Native, 16:9 Compatible

Connections                                 1x VGA (YPbPr/RGB), 1x Composite, USB mouse/service

Contrast Ratio                                                                                22,000:1

Control Unit                                                   USB mouse/service

Display Technology                 Single 0.55″ DC3 DMD DLP™ Technology by, Texas Instruments

Displayable Colors                                                                         1.07 billion

Inputs               1x VGA (YPbPr/RGB), 1x Composite, USB mouse/service

Keystone Correction                                                                      ± 40° Vertical

Light Source Life

Light Source Type                                                                                          195W

Light Source Life         10,000/8,000/7,000/6,000/5,000, (EDU/ECO+/Dynamic/ECO/Bright)

Maximum Resolution                                                                    UXGA (1600 x 1200)

Native Resolution                                                                      SVGA (800 x 600)

Noise Level                                                                                      29dB

Offset                                                                                               115%

Operating Temperature                                                                41-104°F (5-40°C)

Power Consumption                  445W Max (Bright mode), 335W (ECO mode), <0.5W (Standby)

Power Supply                                                AC input 100-240V, 50-60 Hz, auto-switching

Projection Distance                                                                        3.28′ – 32.8′

Projection Lens                                                                               F=2.5 – 3.39, F=17.63 – 31.36mm Manual Focus

Projection Screen Size                                                                   27.7″ – 304.4″

Remote Control                                                                              IR remote control

Throw Ratio                                                           1.94 – 2.16:1 (distance/width) -+ 5% variance

Uniformity                                                                                      80%

Zoom Type                                                                                      1.1x Manual

Dimensions (W x H x D)                                                                 11.73″ x 3.79″ x 9.05″

Security                      Security bar, Kensington locks, password protection, keypad lock

3D Compatibility       1080i50 / 60, 720p50 / 60, Frame-pack: 1080p24, 720p50 / 60,

Over-Under: 1080p24, 720p50 / 60

Computer Compatibility    UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA resized, VESA, PC and                                                     Mac compatible

Horizontal Scan Rate                                                                     15.375 – 91.146 KHz

Optional Wireless                                                                          No

RoHS                                                                                                Compliant

Vertical Scan Rate                                                                   24 – 85Hz (120Hz for 3D)

Video Compatibility                    NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p,                                                                  1080i/p)

Standard Accessories           AC power cord, VGA cable, remote control, carrying

case, batteries for remote, multilingual CD-ROM

user’s manual, quick start guide, and warranty card

Warranty Info                                                                    1 Year Warranty/90 Days Lamp
