MikroTik RB3011UiAS-RM RouterBOARD

The RB3011 is a new multi port device, our first to be running an ARM architecture CPU for higher performance than ever before. The RB3011 has ten Gigabit ports divided in two switch groups, an SFP cage and for the first time a SuperSpeed full size USB 3.0 port, for adding storage or an external 3G/4G modem.
RB3011UiAS-RM Unit comes with 1U rackmount enclosure, a touchscreen LCD panel, a serial console port and PoE output functionality on the last Ethernet port.

Full Specifications

Spec	Detail
CPU	Dual-core 1.4GHz ARM Cortex-A15
Memory	1GB RAM
Storage	128MB
Ethernet Ports	10x Gigabit (10/100/1000), two switch groups
SFP	1x SFP cage
USB	1x SuperSpeed USB 3.0 Type-A
PoE	PoE output on port 10, PoE input supported
Display	Touchscreen LCD panel
Console	Serial console port
Form Factor	1U rackmount enclosure
Software	RouterOS License Level 5, pre-installed

Why Buy from Foretec Online

Genuine, sealed products sourced for the Nigerian market
Transparent Naira pricing with no hidden charges
Fast delivery across Abuja, Lagos, Kano, Port Harcourt, and beyond
Responsive customer support before and after your purchase

Order the MikroTik RB3011UiAS-RM Today

This unit is new and sealed. Browse more MikroTik networking equipment from Foretec, or order the RB3011UiAS-RM now.

SKU: RB3011UIAS-RM Categories: Networking, Routers

Based on 0 reviews

0.0 overall

Be the first to review “Mikrotik RB3011UIAS-RM RouterBOARD 10xGigabit Ethernet, USB 3.0, LCD, RB3011” Cancel reply

There are no reviews yet.

FAQs

What is the CPU and RAM?

A dual-core 1.4GHz ARM Cortex-A15 CPU with 1GB RAM.

Does it support PoE?

Yes, PoE output on port 10, and PoE input is also supported.

Can I rack-mount this device?

Yes, it comes in a 1U rackmount enclosure.

Is the operating system included?

Yes, RouterOS License Level 5 comes pre-installed and licensed.

Is this unit new?

Yes, this unit is sold new and sealed by Foretec.

Specifications
Product code RB3011UiAS-RM
Architecture ARM 32bit
CPU IPQ-8064
CPU core count 2
CPU nominal frequency 1.4 GHz
Dimensions 443 x 92 x 44 mm
RouterOS license 5
Operating System RouterOS
Size of RAM 1 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200’000 hours at 25C
Tested ambient temperature -20°C to 70°C
IPsec hardware acceleration Yes
Powering
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 10-30 V
Max power consumption 30 W
Max power consumption without attachments 10 W
FAN count Passive
PoE in Passive PoE
PoE in input Voltage 10-30 V
PoE-out
PoE-out ports Ether 10
PoE out Passive PoE
Max out per port output (input < 30 V) 600 mA
Max total out (A) 600 mA
Ethernet
10/100/1000 Ethernet ports 10
Fiber
Details
SFP ports 1
Peripherals
Serial port RJ45
Number of USB ports 1
USB Power Reset Yes
USB slot type USB 3.0 type A
Max USB current (A) 1
Other
PCB temperature monitor Yes
Voltage Monitor Yes
Certification & Approvals
Certification CE, EAC, ROHS
IP IP20
