Technical details

BOX CONTENTS

What’s in the box   AC power cord

Documentation

HDMI cable

Warranty card

Set up poster

Power adapter

DISPLAY SPECIFICATIONS

Display size (diagonal)       60.45 cm (23.8″)

Native resolution    FHD (1920 x 1080 @ 60 Hz)

Resolutions supported      1024 x 768

1280 x 1024

1280 x 720

1280 x 800

1366 x 768

1440 x 900

1600 x 900

1680 x 1050

1920 x 1080

640 x 480

720 x 400

800 x 600

Tilt      Tilt: -5 to +25°

Panel technology    IPS with LED backlight

Onscreen controls  Brightness

Color control

Contrast

Exit

Image control

Information

Input source

Language

Management

Menu

OK

Power

Input connector      1 VGA

1 HDMI (with HDCP support)

Horizontal viewing angle  178° horizontal

178° vertical

Display features      Anti-glare

Anti-static

In plane switching

Language selection

LED backlights

On-screen controls

Plug and Play

User programmable

AMD FreeSync™

Contrast ratio          1000:1 static

10000000:1 dynamic

Display scan frequency (horizontal)      Up to 86 kHz

Display scan frequency (vertical)           Up to 75 Hz

Aspect ratio 16:9

Display area (metric)         52.7 x 29.64 cm

Brightness    300 cd/m²

Display colors          Up to 16.7M colors with the use of FRC technology

Display Input Type 1 VGA

1 HDMI 2.0

Display input type note    (with HDCP support)

Pixel pitch     0.274 mm

Response time (typical)    5 ms gray to gray (with overdrive)

Response time footnote number           [1]

Brightness (typical) footnote number  [1]

Contrast ratio footnote number            [1]

WEIGHTS

Weight          2.84 kg

Package weight       4.7 kg

SOFTWARE AND APPLICATIONS

Management software     HP Display Assistant

SECURITY MANAGEMENT

Physical security     Security lock-ready

Physical security footnote number       [3]

DIMENSIONS

Minimum dimensions (W x D x H)         53.98 x 4 x 32.3 cm

Package dimensions (W x D x H)            60.7 x 12.8 x 40.9 cm

BATTERY AND POWER

Power            Input voltage 100 to 240 VAC

Power consumption (on-mode) 19 W

Power consumption (annual)     28 kWh

Power consumption (standby)   0.23 W

Power consumption (off-mode) 0.16 W

Power consumption          22 W (maximum), 20 W (typical), 0.3 W (standby)

CERTIFICATION AND COMPLIANCE

Energy efficiency class      A

WARRANTY

Warranty      1 year
